Hardware Description
9
CP-RIO6-923-F User Guide
www.kontron.com
3
Hardware Description
This chapter describes the board specific features of the CP-RIO6-923-F. The building blocks are:
• Ethernet ports
• CompactPCI bus connectors
The module does not require a power supply. There are no active components on the board.
3.1 RJ45 1000BASE-T Ports
On the RJ45 variants, three Integrated Connector Modules (network magnetics + RJ45) are the physical
interface for the 10/100/1000Base-T ports, there are three 2x4 modules on the CP-RIO6-923-F and three
1x4 modules on the CP-RIO6-923-F12.
The CP-RIO6-923-F supports PICMG 2.16 backplane ports FL1 to FL23 and FLf (Fabric to Fabric Link Port). The
CP-RIO6-923-F12 supports FL1 to FL12. The switch interfaces which are accessible via the module are listed
in the following table.
Table 3-1:
Ethernet Port Mapping
PICMG 2.16 Backplane Port
CP-RIO6-923-F Port Label
CP-RIO6-923-F12 Port Label
FL_f
Fx
-
FL_01
1x
1x
FL_02
2x
2x
FL_03
3x
3x
FL_04
4x
4x
FL_05
5x
5x
FL_06
6x
6x
FL_07
7x
7x
FL_08
8x
8x
FL_09
9x
9x
FL_10
10x
10x
FL_11
11x
11x
FL_12
12x
12x
FL_13
13x
-
FL_14
14x
-
FL_15
15x
-
FL_16
16x
-
FL_17
17x
-
FL_18
18x
-
FL_19
19x
-
FL_20
20x
-
FL_21
21x
-
FL_22
22x
-
FL_23
23x
-
