Hardware Description
14 CP-RIO6-923-F User Guide
www.kontron.com
(*) FL9, FL10 and FL11 are not connected to the backplane on the CP-RIO6-923-F-8M12 variant.
Table 3-7: J5 Connector Pin Assignment
Pin Row A Row B Row C Row D Row E Row F
22 FL_DA19+ FL_DA19- GND FL_DC19+ FL_DC19- GND
21 FL_DB19+ FL_DB19- GND FL_DD19+ FL_DD19- GND
20 FL_DA18+ FL_DA18- GND FL_DC18+ FL_DC18- GND
19 FL_DB18+ FL_DB18- GND FL_DD18+ FL_DD18- GND
18 FL_DA17+ FL_DA17- GND FL_DC17+ FL_DC17- GND
17 FL_DB17+ FL_DB17- GND FL_DD17+ FL_DD17- GND
16 FL_DA16+ FL_DA16- GND FL_DC16+ FL_DC16- GND
15 FL_DB16+ FL_DB16- GND FL_DD16+ FL_DD16- GND
14 FL_DA15+ FL_DA15- GND FL_DC15+ FL_DC15- GND
13 FL_DB15+ FL_DB15- GND FL_DD15+ FL_DD15- GND
12 FL_DA14+ FL_DA14- GND FL_DC14+ FL_DC14- GND
11 FL_DB14+ FL_DB14- GND FL_DD14+ FL_DD14- GND
10 FL_DA13+ FL_DA13- GND FL_DC13+ FL_DC13- GND
9 FL_DB13+ FL_DB13- GND FL_DD13+ FL_DD13- GND
8 FL_DA12+ FL_DA12- GND FL_DC12+ FL_DC12- GND
7 FL_DB12+ FL_DB12- GND FL_DD12+ FL_DD12- GND
6 FL_DA11+ (*) FL_DA11- (*) GND FL_DC11+ (*) FL_DC11- (*) GND
5 FL_DB11+ (*) FL_DB11- (*) GND FL_DD11+ (*) FL_DD11- (*) GND
4 FL_DA10+ (*) FL_DA10- (*) GND FL_DC10+ (*) FL_DC10- (*) GND
3 FL_DB10+ (*) FL_DB10- (*) GND FL_DD10+ (*) FL_DD10- (*) GND
2 FL_DA9+ (*) FL_DA9- (*) GND FL_DC9+ (*) FL_DC9- (*) GND
1 FL_DB9+ (*) FL_DB9- (*) GND FL_DD9+ (*) FL_DD9- (*) GND
