To access the fuse panel the glove box must be removed.
It is removed by slipping the glove box strap off the hook
and letting the door roll down off its hinges. To reinstall,
position the glove box door at an 8 o’clock orientation,
engage the hinge hook formations on the lower edge of
the glove box door with the hinge pins on the lower edge
of the instrument panel. Tilt the upper edge of the glove
box door upward toward the instrument panel enough to
reattach the glove box strap to the door. Rotate glove box
door to closed position. Open and close to insure proper
installation.
Cavity Fuse Description
1 20 Amp Yellow Park Lights, Skim
(Sentry Key)
2 20 Amp Yellow Stop Lights
3 20 Amp Yellow Subwoofer System
4 10 Amp Red Door Switch Defeat
5 10 Amp Red Airbag
6 20 Amp Yellow Rear Wiper
7 10 Amp Red Back-Up Lights, Rear Win-
dow Defroster Relay, ABS
8 10 Amp Red HEVAC
Cavity Fuse Description
9 10 Amp Red Airbag
10 10 Amp Red Instrument Cluster
11 10 Amp Red Solenoids, DRL
12 10 Amp Red Power Distribution Relays,
Skim (Sentry Key)
13 10 Amp Red Turn Signals
14 10 Amp Red Radio
15 10 Amp Red HBL (Rear Window De-
froster) Switch
16 10 Amp Red Headlamp Aim (Export
Only)
17 25 Amp Natu-
ral Front Wiper
18 20 Amp Yellow Cigar Lighter
19 20 Amp Yellow Spare
20 20 Amp Yellow Transmission: Manual -
Clutch Interlock Switch By-
pass Automatic - Ignition
Starter Circuit
