22
TRANSMITTER PROGRAMMING
Transmitter Programming: (Excludes EZ-30DP II model without remotes)
Notes: Remote Transmitters/Transceivers come pre-programmed from the Factory. When re-learning remotes or adding
remotes, ALL your system’s remote codes must be learned at time of programming!! These systems allow storage of up
to 4 different remote codes in memory. The EZ-64TW1 II/74TW2 II/84FM II systems include both a 1-way remote
transmitter and an LED or LCD remote. The “Sidekick” transmitters for the TW1/TW2 systems are a special model that is
not compatible with standard EZ-31/3/4DP II remotes. EZ-31/33/34DP II and EZ-64TW1 II/74TW2 II/84FM II remotes are
not interchangeable.
1. Turn key to the ON position. (Do not start vehicle) Pink wire must be connected!
2. Press Program/Valet button 4 times. Wait for the unit to flash the parking lights and/or honk horn exactly 4 times.
3. EZ-34 series II: Press Button #1 (Lock) of the transmitter to be learned. EZ-64TW1 II/74TW2 II/84FM II: Both the Lock
& Unlock buttons must be pressed. You should get 2 light flashes and 2 horn honks indicating the code-learn. Now the
unit is waiting for a 2
nd code, so repeat this step as needed with up to 3 additional remotes. The unit will flash the lights
in succession after each code learned for up to 4 codes. (3 flashes after the 2
nd
code, 4 flashes after the 3
rd
code and 0
for 4
th
code.) If all 4 codes are learned, the unit will automatically exit code learning mode, otherwise turn key OFF.
IGN
OFF
WAIT FOR
4 FLASHES
PRESS 4X's
FLASH 2, 3, or 4 X's
EZ-64TW1 II/74TW2 II
EZ-34 II Series
IGN
OFF
PRESS TOGETHER
LOCK &
UNLOCK
PRESS LOCK
PRESS START
(2-Way systems only)
COMPLETE
ON EZ-31
