17
OPTIONS PROGRAMMING
To Engage Option Programming:
1. Open hood, If no hood pin switch is installed, then ground the Gray wire. Turn Key to the ON position. Do not start
vehicle Pink wire must be connected!
2. Press the program Valet button 5 times. Wait for the unit to flash the lights and/or horn honk 5 times.
3. Push the valet program button the number of times that corresponds to the option number desired (1-22X). You
must get a light flash and/or honk after each button press. If the system did not flash the lights and/or honk, then it
did not register your press. Press carefully and do not lose count.
4. For EZ/33/34DP II or 64TW1 II/74TW2 II/84FM II: When you reach the desired option #, Press button #1 Lock or
#2 Unlock to change the option. (Some option numbers use ALL 4 remote buttons to select settings)
5. For EZ-30/31DP II: (No Lock button) Tap the brake pedal to toggle through the option values: Tap the brake once
(lights flash 1X; Tap the brake pedal again (Lights flash 2X) tap 3 or 4 times for options that have 3 or 4 values.
6. When finished, turn Ignition OFF, close hood (or un-ground Gray wire) and check for changed features.
* = Default Value
Option
#
Option Description Option Values
Button #1
LOCK
Button #2
UNLOCK
1. Engine Monitoring Tach (Engine RPM) or Tachless Tach Tachless*
2. Autolock with RPM/Ignition ON (RPM/Ignition) or OFF. ON * OFF
3.
Door Lock Pulse Time
0.5 Sec. (Standard) OR
3.0 Sec. (European Vacuum)
3 Sec. * 0.5 Sec.
4. Double Unlock Pulse Single or Double Unlock Pulse Double * Single
5. Data Port Protocol OFA = 1-Way / SL= 2-Way 1-Way * 2-Way
6. Double button press for remote
start and Trunk release
ON or OFF ON * OFF
7. Horn Chirps on remote start ON or OFF ON * OFF
8. Lock During and After Remote
Start Abort
ON or OFF OFF * ON
9. Tan Wire Output function Trunk or Dome Light Output Dome * Trunk
10. Wake up Pulse on Unlock (1-
sec +12V to IGN)
ON or OFF ON * OFF
