Vermont Casting 2490 - Manual (Page 30)

30
Resolute Acclaim Woodburning Stove
2000893
Resolute Acclaim Woodburning Stove
Model 2490 (continued)
Item Description Part Number Item Description Part Number
19. Combustion Package 1602497
20. Sealing Plates (2) 1301859
21. Arch Brick Retainer 1600154
22. Left Arch Brick 1600151
23. Right Arch Brick 1600152
24. Rear Grate 1301851
25. Front Grate 1301852
26. Pit Plate 1301804
27. Andiron (2) 1301806
28. Tie Rod (4) 1601640
29. Left End See Chart Pg. 30
30. Ash Pan 5005775
31. Left Inner Side 1301855
32. Side Firebrick (2) 1600153
33. Left Shoulder Plate 1301863
34. Leg (4) See Chart Pg. 30
35. Package Support Plate 1301809
36. Bottom 1301854
37. Right Shoulder Plate 1301864
38. Ashlip See Chart Pg. 30
39. Air Valve 1301814
40. Air Valve Shaft 1600621
41. Air Valve Handle / Door Handle 1600663
51. Right Inner Side 1301856
52. Right End See Chart Pg. 30
53. Damper Handle Stub w/ Set Screw 30002720
54. Damper Handle 1600664
55. Damper Handle Screw 1201310
56. Air Manifold 1301803
57. Front 1301861
58. Glass Retainer (2) 1601399
59. Glass 1401120
61. Door See Chart Pg. 30
62. Door Hook 1600155
63. Door Handle Shaft 1600623
64. Latch Retainer 1201843
65. Compression Spring 1600551
66. Upper Door Pin 1600550
67. C-Clip 1600553
68. Pin, Hinge Bottom 1600419
69. Nut, Hex 5/16-18 1203279
Shell Enamel Parts - Resolute Acclaim
Enamel Left Right Flue Flue
Color Top Side Side Collar Cover Ashlip Door Leg
Classic 1301862 1301857 1301858 1301816 1301817 1301819 1301865 1301833
Biscuit 30003118 30003119 30003120 30003121 30003122 30003117 30003123 30003116
Bordeaux 2321862 2321857 2321858 2321816 2321817 2321819 2321865 2321833
Chestnut
Brown 30003127 30003128 30003129 30003130 30003131 30003126 30003132 30003125
Ebony 30003136 30003137 30003138 30003139 30003140 30003135 30003141 30003134
Forest
Green 2311862 2311857 2311858 2311816 2311817 2311819 2311865 2311833
Midnight
Blue 2371862 2371857 2371858 2371816 2371817 2371819 2371865 2371833
Sand 1321862 1321857 1321858 1321816 1321817 1321819 1321865 1321833
Suede
Brown 30002560 30002561 30002562 30002563 30002564 30002559 30002565 30002558
VT. Classic
Green 30003145 30003146 30003147 30003148 30003149 30003144 30003150 30003143
