Parts list – Evolution Engines Gas RC User Manual
Page 16

EN
16
Parts List
#
Description
Part
1
Cylinder Head Screws
(6) 10GX
EVO40120
2
Spark Plug ¼-32 thread
EVOG10350
3
Cylinder Head 10GX
EVOG10103
4
Cylinder Head Shim:
60NX, 10GX
EVO060112
5
Cylinder Piston Set 10GX EVOG10203
6
Wrist Pin with Clips:
52NX, 60NX, 10GX
EVO052213
7
Connecting Rod 10GX
EVOG10204
8
Prop Washer & Nut:
1/4 x 28
EVO040228
9
Prop Driver 10GX
EVOG10219
10 Spacer Washer;
120NX, 10GX
EVO91225
11
Front Bearing;
120NX, 10GX
EVO91109
12 Crankcase with index
pin 10GX
EVOG10101
13
BB, Rear (Open Race):
52NX, 60NX, 10GX
EVO052110
14
Drive Key; 120NX, 10GX
EVO91218
15
Crankshaft 10GX
EVOG10210
16 Rear Cover with Gasket:
52NX, 60NX, 10GX
EVOG10102
17
Back Cover Screw (4)
10GX
EVO40134
18 Muffler Assy 10GX
EVOG10601
19 Muffler Long Screw
120NX, 10GX
EVO120616
20 Muffler Mounting
Screw Set
EVO100E46A
#
Description
Part
21
Carb Assy 10GX
EVOG10801
22 Carb Mounting O-Ring
EVOG10816
23 Carb base washer
EVO46826
24 Carb Retainer (Drawbar)
10GX
EVOG10129
25 Evo 10GX Ignition Unit
EVO10101
26 Carb Body & Spray Bar
10GX
EVOG10863
27 Regulator Case
mid-section 10GX
EVOG10872
28 Regulator Case Top 10GX EVOG10874
29 Regulator Spring 10GX
EVOG10880
30 Regulator Gasket Set
10GX
EVOG10875a
31
Regulator Piston Set
10GX
EVOG10876a
32 Carb Barrel 10GX
EVOG10813
33 Idle Needle Assy 10GX
EVOG10810
34 High Speed Needle
Assembly 10GX
EVOG10812
35 Hi Speed Needle 10GX
EVOG10829
36 Fuel Nipple-12114:A
EVO100114
37 Idle Needle Stop
Screw-46825F:A
EVO100825F
38 Throttle Arm
EVO100864A
39 Carb Barrel Spring 10GX
EVOG10814
40 Carb regulator screws
(4) 10GX
EVOG12123
41
Engine Gasket Set:
60NX, 10GX
EVO060416
2 YEAR LIMITED WARRANTY
What this Warranty Covers - Horizon Hobby, Inc.,
(Horizon) warrants to the original purchaser that
the product purchased (the “Product”) will be free
from defects in materials and workmanship for a
period of 2 years from the date of purchase.
What is Not Covered - This warranty is not trans-
ferable and does not cover (i) cosmetic dam-
age, (ii) damage due to acts of God, accident,
misuse, abuse, negligence, commercial use,
or due to improper use, installation, operation
or maintenance, (iii) modification of or to any
part of the Product, (iv) attempted service by
anyone other than a Horizon Hobby authorized
service center, (v) Product not purchased from
an authorized Horizon dealer, or (vi) Product not
compliant with applicable technical regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE,
HORIZON MAKES NO OTHER WARRANTY OR REP-
RESENTATION, AND HEREBY DISCLAIMS ANY AND
ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT
LIMITATION, THE IMPLIED WARRANTIES OF NON-
