Technical Data MODEL 4630 REFRAD REFERENCE RADIATOR
4 © EMC TEST SYSTEMS, L.P. – MARCH 2002
REV F – PN 399214
TECHNICAL DATA
COMB GENERATOR
POWER SUPPLY
One (1), internal 12 VNIMh 3.5 Ah.
Factory serviceable only.
OUTPUT SIGNAL – COMB SPECTRUM
BALUN USED
RANGE
(MHz)
LINE SPACING
(MHz)
OUTPUT
POWER
Per line,
typical (dBm)
C 0.01-1 0.01 -17 to -20
B 1-100 1 -10 to –18
A 100-1000 5 -10 to –30
CAUTION For measuring the direct output signal, the comb
generator has to be connected via an attenuator (attenuation 30 dB)
to protect the test receiver or spectrum analyzer.
REMOTE CONTROL
Connection is made with Hewlett Packard low-loss plastic fiber
optic cable with simplex-type connectors.
TEMPERATURE RANGE
+5 degrees to +30 degrees C.
Archived 3/18/10
