Technical Data
MODEL 4630 REFRAD REFERENCE RADIATOR
8
© EMC TEST SYSTEMS, L.P. – MARCH 2002
REV F – PN 399214
ACCESSORIES
TRANSMIT ANTENNAS
The system includes three antennas:
Long dipole antenna, element length 650mm
(for use with 10 kHz spacing)
Square loop, side length 300mm
(use for generating magnetic field)
Short dipole antenna, element length 200mm
(for use with 1 MHz and 5 MHz spacing)
TRIPOD MOUNTING ACCESSORIES
The following tripod accessories are included with the system:
Support rod
Support base
Clamp block
FIBER OPTIC LINK
Fiber optic link: Simplex connectors, standard length: 10m. Fiber
optic link
COAXIAL ADAPTER
Provides a means to adapt the output of the comb generator to a
type “N” coaxial connector.
REFERENCE CABLE AND ATTENUATOR
(NOT SUPPLIED WITH SYSTEM)
Reference cable: Coaxial cable, length 25 cm.
Connectors: Type BNC male – Type N male
Attenuator:30 dB, BNC
Archived 3/18/10
