8.0 Specifications
8.1 Electrical Specifications
With Standard Bow-tie
Elements
With Optional End Plates
Frequency Range: 26-3000 MHz 26-3000 MHz
Input Impedance 50 Ω 50 Ω
VSWR: 2:1 average 2:1 average
CW power:
26 MHz – 60 MHz500 W60
MHz – 600 MHz1kW600
MHz – 1GHz750W1 GHz –
3 GHz500 W 26 MHz – 60 MHz500 W60
MHz – 600 MHz1kW600
MHz – 1GHz750W1 GHz –
3 GHz500 W
Symmetry: +/- 0.5 dB +/- 0.5 dB
Connector: N female N female
8.2 Physical Specifications
With Standard Bow-tie
Elements
With Optional End Plates
Height (bow-tie):
75 cm
29.5 in 75 cm
29.5 in
Width (bow-tie):
135 cm
53.1 in 136 cm
53.5 in
Depth (boom length):
90 cm
35.4 in 132 cm
51.9 in
Weight:
4 kg
8.8 lb 6.8 kg
14.9 lb
