Ranges and Specifications

| 13

3.0 Ranges and Specifications

Ranges

Autorange:

1.00 mA–1.000 A

Range 1:

1.00 mA–10.0 mA

Range 2:

3.1 mA–31.6 mA

Range 3:

10.0 mA–100.0 mA

Range 4:

0.031 A–0.316 A

Range 5:

0.100 A–1.000 A

Specifications

Typical Frequency Response:

9 kHz–70 MHz ±2.0 dB

Linearity:

±0.5 dB

At lower levels, the linearity for

Range 1 deviates within ±0.5 dB

due to noise. The remaining ranges

follow the ideal curve as shown for

Range 2 in Typical Frequency

Response on page 15.

Fiber Optic Connectors:

Standard FSMA

Fiber Optic Cable:

200 micron, Graded Index,

Multimode, Max Length 1 Km

Readout:

HI-4416 Digital Readout/Control

Unit
