Page — 8 HI n 3637 Manual
Figure 3 n n 1
End View of Charger
screwdriver to pry loose the fuse assembly,
which is located below the AC connector.
Remove the assembly and locate the small
PC Board on the back side. Slide the PC
board from right to left to remove it from the
fuse assembly: rotate this board so that the
desired voltage indicator is right-side up,
then reinsert it into the fuse assembly. The
required voltage should now be visible in the
viewing window. Firmly reseat the fuse
assembly back into the power entry module.
The charger is now ready to use. See section
4 for the battery charging procedure.
NOTE:
If the correct voltage is still not visible,
contact Holaday Customer Service for
