HI

n

3637 Manual

Page — 5

Instrument Package:

Dimensions (Including

connectors):

165 mm x 95 mm x 70 mm

(6.5 in x 3.75 in x 2.75 in)

Weight:

0.88 kg (31 oz)

Standard Probe:

Type:

External, three-axis multi-turn loop

I. D. (each loop):

110 mm (4.33 in)

O. D. (each loop):

116 mm (4.57 in)

Area (each loop):

0.010 m² (15.5 in²)

Overall Diameter:

127 mm (5 in)

Handle Length:

292 mm (11.5 in)

Cable length:

1.5 meters (5 ft)

Weight:

0.45 kg (16 oz)

Optional X100 Probe:

Type:

External, three-axis single-turn loop

Loop Dimension:

12.7 mm (.5 in) per side

Area (each loop):

6.35 mm² (.25 in²) per side

Overall Diameter:

34.3 mm (1.35 in)

Overall Length:

292 mm (11.5 in)

Cable length:

1.5 meters (5 ft)

Weight:

0.31 kg (11 oz)
