38 Menu Options, Settings, Command Set www.ets-lindgren.com
 Mode 2 —Prints summary ticket. This is the default mode. The
HI-1710A sends a pre-formatted summary report through the RS-232
serial port each time the probe is zeroed. This is most useful when
using Peak Hold mode. With this configuration, a serial input printer set
up to print adhesive-backed labels can be connected to the RS-232
serial port. After scanning an oven, the meter is zeroed. On zeroing, a
ticket is printed with the maximum leakage observed as well as several
system test parameters.
The output is formatted for a standard 3 1/2-in x 15/16-in label
(for example, Avery® label 4013). Line feed characters are
transmitted following the formatted data to advance one additional
label space with each formatted output. By printing the report on
every other label, the labels can be removed from the backing
more conveniently.
 Mode 3 —Does not print summary ticket when zeroed. Changes the
output format of the status messages S0 –S8. The transmitted
summary messages are shortened for easier adaptation to a computer
interface program.
The zero command does not transmit a formatted report as in
mode 2. In mode 3 the transmitted status messages end with only
a carriage return terminator (CR). In modes 0, 1, and 2, the
messages end with a carriage return and a line feed (CR/LF).
