Page 22
22
Operation
www.ets-lindgren.com
Menu Navigation
HI-1710A Front Panel
See Menu Options, Settings, and Command Set on page 27.
1.
To display the menu, press any arrow button on the front of the
HI-1710A.
2.
Press the down arrow button to move the highlighted selection down
one item at a time, and press the up arrow button to move the
highlighted selection up one item at a time.
3.
With the item you want to change highlighted, press the left/right arrow
button to move to the settings for that item.
4.
Press the up or down arrow buttons to scroll through the available
settings for the highlighted item.
5.
Highlight the desired setting and then release the buttons. After
approximately three to four seconds the display will return to the main
screen with the new/highlighted settings in effect.
(Version 3.XX only) Press the ZERO button once on the front of the
HI-1710A to go back one level in the menu. Do not to press the
button more than once or you will zero the probe.
