Using the Pneumatic Polarization Option
A
DJUSTING
A
IR
P
OLARIZATION
S
PEED
Damage to the antenna may occur if the air
polarization speed is set too high. Adjust the
flow control valves to prevent damage.
Flow control valves attached to the air cylinder allow variable speed on
polarization cycling. Use a small screwdriver to adjust the air flow through the
two 90-degree fittings.
