ETS-Lindgren 7-TR Tripod Positioner User Manual
Page 32
32
Mounting a Model 3106 Series Antenna
www.ets-lindgren.com
6.
Attach mount adapter to the Model 3106B:
Using the two screws removed in step 4, insert the screws
through the lip on the vertical part of the mount adapter and
into the two holes on the antenna. Tighten to secure.
Using the screw removed in step 3, insert the screw through
the horizontal part of the mount adapter and into the mount
block on the antenna. Tighten to secure.
