Specifications
|
15
3.0 Specifications
Electrical Specifications
M
ODEL
3112
Frequency Range
100 MHz—1 GHz
VSWR Ratio (Average)
< 1.6:1
Maximum Continuous Power
800 W
Peak Power
1.5 kW (Type N, female connector)
2.5 kW CW (EIA 1 5/8-in flange connector)
Impedance (Nominal)
50 Ω
Connector
Type N, female
EIA 1 5/8-in flange
Front-to-Back Ratio
20 dB
Cross Polarization
20 dB minimum
M
ODEL
3106B
Frequency Range
200 MHz—2.5 GHz
VSWR Ratio (Average)
<1.6:1
Maximum Continuous Power
800 W
Peak Power
1600 W
Impedance (Nominal)
50 Ω
Connector
Type N, female
Front-to-Back Ratio
20 dB
Cross Polarization
20 dB minimum
