Introduction
| 11
M
ODEL
3112 P
OSITIONING
S
YSTEM
The Model 3112 features an option
for a fixed height pneumatic-assisted
polarization positioning system. The
position system is ideal when using
the Model 3112 for immunity testing.
Power Supply: 160 mA
120 VAC
Optional 220 VAC available
Pneumatic Interface: 50–80 PSI
Weight: 181.43–226.76 kg
400–500 lb
Maximum Height: 355.6 cm
140 in
Maximum Load: 194.13 cm
76.43 in
ETS-Lindgren Product Information Bulletin
See the ETS-Lindgren Product Information Bulletin included with your shipment
for the following:
 Warranty information
 Safety, regulatory, and other product marking information
 Steps to receive your shipment
 Steps to return a component for service
 ETS Lindgren calibration service
 ETS Lindgren contact information
