Operation | 51
A RRANGING M ULTI -C AMERA I MAGES
1. Power up all cameras. Allow cameras to complete self-test routine.
2. Open Internet Explorer and type IP address of one camera. Type
the IP address for one camera in the address bar in the browser
window.
3. Open a second Internet Explorer browser window and type the
next IP address. Repeat this step until you open a browser window for
each camera on the network.
4. Arrange browser windows. Drag windows to desired location on
monitors. Re-size windows as required.
S ETTING U P A M ULTI -S CREEN C ONFIGURATION
You can configure up to four cameras as a group and up to four
groups, for a maximum of 16 cameras.
1. Power up all cameras. Allow cameras to complete self-test routine.
2. Select desired configuration. On the camera home screen, click the
button under Multi-screen that corresponds to the desired image
configuration.
3. Enter the IP address or the host name. Click Setup and enter the
information for the first camera, using a maximum of 128 characters.
For example:
 For an IPv4 address: http://192.168.0.10:8080
 For an IPv6 address: http://[2001:db8:0:0:0:0:0:1]:8080
When using the host name, it is necessary to configure the
DNS settings of the computer that will be used for the multi-screen
display (IPv4 network). If you purchased the computer from
ETS-Lindgren, it was shipped to you pre-configured.
