EFCO S5600 Concealed Vent User Manual
Page 9
EFCO CORPORATION 6/2012 PART NO. Y310
Page 9 of 13
Series 5600 Curtain Wall Concealed Vent Installation Instructions
Section V: Installation / Pressure Plate
Installation / Pressure Plate
A.)
Complete glazing and exterior covers per the typical S-5600 Outside Glazed
Installation Instructions.
Side Block
Vent Adaptor
Gasket
Isolator
Gasket
Gasket
Anchor
Pressure Plate
Cover
