In Ground Model 200iPX/250iPX Motorcycle Dynamometer Installation Guide
C H A P T E R 4
Basic CPI Operation
4-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BASIC CPI OPERATION
The control panel may be mounted to either side of the tray for easy access by the
dyno user while seated on the bike. The graphics on the control panel are grouped
together according to function and color coded for ease of identification.
A description of the functions and displays follows:
Figure 4-1: Control Panel Features
FORWARD
BACK
STATUS
Flashing—Error
refer to manual
WHEEL CLAMP
CLOSE
OPEN
CAUTION
FRONT WHEEL MUST BE SECURED AT ALL
TIMES. TIE DOWN STRAPS MUST BE
USED TO STABILIZE THE MOTORCYCLE.
Steady
indicator
light=wheel
secure.
LEFT RIGHT
BLOWERS
A/F RATIO
PUMP
STARTER
On—Ok
C
A
R
R
I
A
G
E
Risk of injury.
Read and follow all
instructions and safety
precautions.
Eye and Ear
protection required.
Clean the A/F
Ratio Pump
filter regularly.
WARNING
97
41
51
60
NOTICE
S
H
U TDOW
N
DYNO
refer to manual
status indicator
light
