Setup (Main Unit)
Overview !
Document feeder
tray
Recording paper
set lever
Diverter
Paper stacker
Paper tray
Document guide(s)
Front cover open
lever
Serial interface connector
(Used to connect your PC with the
included RS232C cable. For system
requirements, see page 79.)
Document exit
Microphone
(Used to talk to the other party
when using the speakerphone.)
Document entrance
Battery cover for
main unit
Assembly !
Spare battery charger
(beneath the cover)
Speaker
Antenna
SPARE CHARGE
indicator
CHARGE indicator
Charge contacts
Installing the battery cover on the main unit !
Close the battery cover on the main unit.
¡ You can insert a spare battery beneath the cover to
charge (see page 112).
Battery cover for
the main unit
