42
MIDI Implementation
Mopho x4 receives MIDI data according to the mode controls under G
LOBAL
. In
addition, there is interaction between some of the Program parameters that
determine the overall response of Mopho x4 to MIDI data.
Following are the Global parameters that affect response to MIDI:
MIDI Channel: ALL, 1…16 — Selects the MIDI channel to send and receive
data, 1 to 16. All receives on any channel.
Clock: see table — Selects the MIDI clock status as follows:
Display MIDI Clock Setting
Internal MIDI clock is neither sent nor received
MIDI Out MIDI clock is sent
MIDI In MIDI clock is received
MIDIn/Out MIDI clock is received and transmitted
MIDI Parameter Send: NRPN, CC, Off —
Changes to the values of Mopho x4’s
front panel controls are transmitted via MIDI as Non-registered Parameter
Number (NRPN) controllers or as Continuous Controllers (CC). Transmission of
parameters can also be turned off.
MIDI Parameter Receive: All, NRPN, CC, Off — Sets the method by which
Mopho x4 receives parameter changes via MIDI. As with transmission, NRPNs
are the preferred method, though some controllers may only be able to send
CCs.
MIDI Control: Off, On — When On, the synth will respond to MIDI controllers,
including Pitch Wheel, Mod Wheel, Pedal, Breath, Volume, and Expression.
MIDI SysEx: Off, On — When On, the synth will respond to received MIDI
SysEx messages, and will transmit them, when prompted, to the MIDI Out.
