Step 7, Secure bottom whiteboard assembly – Copernicus SRC2 User Manual
Page 7
SRC1_SRC2 - Version A - Released 4 April 2014 - Copernicus Educational Products Inc.
7
Whiteboard Bracket
x 2
Secure Bottom Whiteboard Assembly
You will need:
(Not to Scale)
Actual Size:
C
F
B
F
H
Repeat on other side
Choosing holes:
Depending on which hole
you chose in Step 6.
M6 x 35mm
x 2
B
M6 x 15mm
x 2
C
M6 Lock Washer
x 4
F
M6 Acorn Nut
x 2
H
