Page 2
SRC1_SRC2 - Version A - Released 4 April 2014 - Copernicus Educational Products Inc.
Hardware
Actual Size
Contents - Box 1
Before beginning, you should have:
Additional tools required:
Shared Reading Center - Parts
In Box 1
M6 Allen Key
(Not to Scale)
1x
Open Tub
4x
(CC4068)
Large Divided Tub
2x
(CC4069)
10 lbs Weight Limit
Small Tub
4x
(CC4070)
5 lbs Weight Limit
Open Tub
8x
(Cc4068)
10 lbs Weight Limit
Top Stretcher “A”
1x
Hole
Hole
Ultra-Safe Premium
Adjustable Book Ledge
1x
(PABL-SRC)
SRC1
SRC2
M6 Acorn Nut
2x
M6 x 40mm
18x
A
M5 Lock
Washer
2x
E
M6 Lock
Washer
28x
F
Nylon Washer
2x
G
Tub Stretcher “C”
6x
Tub Stretcher “B”
2x
Short Stretcher “D”
3x
Thick Stretcher “E”
1x
Right Side Frame
1x
(pre-assembled)
3” Twin Wheel Locking Caster
4x
Whiteboard Assembly
1x
H
Telescoping Extensions
2x
(1 left, 1 right)
Hole
Hole
Front Leg
1x
Rear Leg
1x
Chart Loop Hooks
2x
(Not to Scale)
Page Paws
2x
(Not to Scale)
Whiteboard Bracket
2x
Top View
Side View
Knob
(Not to Scale)
2x
Adjustable wrench
Rubber Mallet
SRC1
SRC2
M6 x 15mm
2x
C
M5 x 40mm
2x
D
M6 x 35mm
8x
B
OR
10 lbs Weight Limit
Ultra-Safe Premium
Adjustable Book Ledge
1x
(PABL-SRC)
