Step 2, Attach rear frame legs to front frame assembly – Copernicus SOSE1 User Manual
Page 6
3
You will need:
(Not to Scale)
Attach Rear Frame Legs to Front Frame Assembly
With the Front Frame Assembly and Rear Frame Legs lying on their sides, align the
holes at the tops of the Frames
- Fasten with two Bolt B’s, Washer D’s & Nut E’s
- Tighten Bolts
Repeat with remaining Rear Frame Leg
x 4
D
x 4
E
x 4
B
Actual Size:
SOSE - Version E - 1 June 2009 - Copernicus Educational Products Inc.
