Copernicus RC005 User Manual
Page 7
RC005 Assembly Instructions - Version B - Released 21 October 2011 - Copernicus Educational Products Inc.
7
Install Book Ledge
There are four (4) positions on the front and
five (5) on the back of the unit for your
convenience. Choose the one that works
best for your classroom.
1) Insert one hook into the appropriate hole on
one side of the Whiteboard Frame
2) Pull out opposite hook & snap into place
Note: The spring tension is designed to
discourage children from unhooking the
Book Ledge
Book Ledge x 1
You will need:
(Not to Scale)
Actual Size:
8
Attach ‘S’ Chart Hooks & Chart Loop Hooks
‘S’ Chart Hooks x 2
Chart Loop Hooks x 2
You will need:
(Not to Scale)
Actual Size:
Snap
Tip: place empty hardware bags over
the frame to prevent scratching.
Lined Magnetic Dry Erase Board x 1
