RC005 Assembly Instructions - Version B - Released 21 October 2011 - Copernicus Educational Products Inc.
4
Install Bottom Racks into Frame Channels
Bottom Rack x 2
You will need:
(Not to Scale)
x 8
Actual Size:
C
2 Person Task
x 8
F (lock nut)
! Install Bottom Racks
before fastening screws
Note: do not over tighten
or Rack will not slide
C
F
C
F
3
Install Casters
2” Caster x 4
You will need:
(Not to Scale)
Actual Size:
Note: If you cannot push the casters
in by hand, try placing an adjustable
wrench between caster wheels and
then tapping with a rubber mallet !
