RC005 Assembly Instructions - Version B - Released 21 October 2011 - Copernicus Educational Products Inc.
1
Install Board’s Bottom Stretcher
Front Frame x 1 Bottom Stretcher x 1
You will need:
(Not to Scale)
x 2 x 2
Actual Size:
B E
DO NOT TIGHTEN ANY FASTENERS UNLESS INSTRUCTED
B E
E B
! Remove packaging
and slide back into
channel
2
Assembled Front Frame x 1 Rear Frame x 1
You will need:
(Not to Scale)
x 2
Actual Size:
D
x 2
E
x 2
A
Fasten Front & Rear Frame Together
!
Note placing the unit on its side
will make this assembly easier
D
E
A
D
E
A
Bottom
Channels
should face
each other
!
Rotate into
position
