Step 4, Important - assembly option – Copernicus PDR11 User Manual

Page 7

PDR11 - Version A - 2 November 2012 - Copernicus Educational Products Inc.

White Board
x 2

Peel plastic film
off of Whiteboards
before assembly

Actual Size:

You will need:

(Not to Scale)

B
x 6

F
x 6

D
x 6

E
x 6

Attach Board

Low position

High position

Attach 1 top corner
and 2 bottom
corners (board
shown in lowest
position).

Use top holes
for High position

Choose the desired position for the boards

IMPORTANT - Assembly Option

Board in Low
Position

Please follow
Step 5-6-7- 8A,
then continue
until the end

Board in High
Position

Please follow
Step 5-6-7- 8B,
then continue
until the end
