Step 1 – Copernicus PDR11 User Manual
Page 4
PDR11 - Version A - 2 November 2012 - Copernicus Educational Products Inc.
1
Side Frame
x 2
Bottom Stretcher
x 2
Tub Channel Stretcher
x 2
A
x 8
D
x 8
Keep Tub Channel Stretcher assembly loose.
Install short side facing upward.
!
Assemble fully but
do not tighten.
!
Attach Stretchers to Side Frames
A
A
D
D
You will need:
(Not to Scale)
Actual Size:
