Copernicus LW431 - Manual (Page 2)

LW430 - Version A - 03 October 2014 - Copernicus Educational Products Inc.
Assembly
Wrench
1x
(Not to scale)
A
B
Contents - Box 2
Caster Hardware Bag
Hardware
Actual Size
Before beginning, you should have:
In Box 1
Library On Wheels - Parts
Contents - Box 1
5” Caster
(2 with brakes)
4x
Straight
Stretcher
3x
Bent
Stretcher
2x
Assembly
Spanner
1x
Rubber Stop
8x (4 required)
Tub Support
4x
Back Stop
2x
C
Divided Tub
9x
D
Caster Large
Washer
4x
E
Caster Lock
Washer
4x
F
Caster Nut
4x
Rubber mallet
Additional tools required:
Adjustable wrench
End Frame
2x
Max Load
10 lbs/tub
M6 x 55mm Bolt
22x
(43255)
M6 Acorn Nut
8x
(43271)
22x
M6 Lock Washer
(43273)
