Build Bottom Half of Frame
You will need:
(not to scale)
ASSEMBLY OPTION A - FULL HEIGHT UNIT
2A
Actual Size:
8x 16x
A A
Pre-assembled End Frame x 2
C D
!
Note orientation of channels
on end frames - they should
be facing inwards.
2-Person Task
7
Fit the middle frame built in the previous step
in between end frames.
C
D
E
Press Glide firmly
into the feet of the
unit. Use a rubber
mallet to tap in if
necessary.
Use lowest
hole to install
middle frame
stretchers
1
3
3
2
8x 8x
E C
Glide x 4
A A
A A
A D
A D
