Assembly option b - half height unit, Tighten all hardware now – Copernicus LLS300 User Manual
Page 17
LLS300 - Version B - 21 November 2013 - Copernicus Educational Products Inc.
You will need:
(not to scale)
ASSEMBLY OPTION B - HALF HEIGHT UNIT
4B
Actual Size:
17
Use lowest
hole to install
middle frame
stretchers
Install Storage End Frames
on
FRAME 2
TIP - the higher edge is the
FRONT of the unit.
You can use lettering to label
the unit if desired (not included).
TIGHTEN ALL
HARDWARE NOW!
A
8x
C
A
D
8x
A
A
A
D
