Page 15
LLS300 - Version B - 21 November 2013 - Copernicus Educational Products Inc.
Build Middle Sections
You will need:
(not to scale)
ASSEMBLY OPTION B - HALF HEIGHT UNIT
2B
Actual Size:
16x
16x
Middle Frame x 4
A
A
Stretcher x 8
C
D
A
A
A
A
A
A
D
D
D
2-Person Task
Note orientation of
channel when installing
middle frames.
!
Note orientation of
channel when installing
middle frames.
!
TIGHTEN ALL HARDWARE FIRMLY
x1
x1
Top Shelf x 1
FRAME 2
FRAME 1
15
