Copernicus BTHC3 - Manual (Page 7)

BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
7
Assemble Book Display Rack
You will need:
(Not to Scale)
Actual Size:
Rack 1
Rack 2
Rack 3
Rack 4
Rack 5
Top Rack
Main Rack
A
F
Tip, work from largest
to smallest rack
1
2
3
4
5
M6x15mm Bolt
x 10
A
M6 Acorn Nut
x 10
F
Bolt is threaded through
the rear of the back frame.
Tighten bolts securely.
x 10
M6 Lock Washer
E
E
Hook bottom first then
bolt.
