Page 2
BTHC2 - Version A - Released 3 September 2013 - Copernicus Educational Products Inc.
Bottom Whiteboard
Stretcher
1x
F
M6 Acorn Nut
10x
Contents - Box 1
M6x35mm Bolt
8x
Allen Key
(Not to Scale)
1x
Before beginning, you should have:
Additional tools required:
Rubber Mallet
Contents - Box 2
Pencil Basket (#1607)
1x
Book Display Rack
(#31041)
needs assembly
1x
Open Tub
4x
(CC4068)
10 lbs Weight Limit
M6 Lock Washer
22x
M6x45mm Bolt
4x
Chart Caddy Center - Premium Parts
Front Frame with
Whiteboard
1x
Back Frame
1x
Long Bend Arm
2x
Short Bend Arm
2x
2” Twin Wheel
Caster with brake
4x
Chart Caddy
Stretcher
1x
Knob
2x
M6x15mm Bolt
10x
M6x20mm Bolt
8x
Bottom Rack
2x
Ultra Safe Book Ledge
1x
(PABL30)
Loop Hook
2x
“S” Hook
2x
Page Paw
2x
A
B
C
D
E
M6 Lock Nut
8x
G
BTHC2
Hardware
Actual Size
Chart Caddy
10x
Hang Tags
100x
Telescoping Arms
1x Right
1x Left
M6 Nut
4x
H
