6
Parts List
Ref. No. Description Gladiator Warrior 3-Up Warrior 6-Up
1 Visor T13210 T13210 T13211
2 Bezel T07554 T07554 T07558
3 Lighthead See Table Contact Factory Contact Factory
4 Bracket, Lighthead/Suction Cup T13208 T13208 T13209
5 Suction Cup Assy S95332 S95332 S95332
6 L-Bracket T13225 T13225 T13224
7 Shroud T13212 T13212 T13213
Not Shown Screws, Black #6-5/8" Phillips T13241 T13241 T13241
Not Shown Button, Pattern Change T13219 T13222 T13219
Not Shown Cord, Cigar T15948 T15948 T15948
Not Shown Gasket (Visor option only) T09795 T09795 T09795
Not Shown Tape, Reflective, Mylar (Visor only) T13239 T13239 T13239
Gladiator™ LCLED™ Version
T04583 Blue
T04584 Amber
T04585 White
T04590 Red
S95335 Spacer, Painted
S95334 Mtg. Brkt, Pemserted
T06598 6-32X1/4 Screw
Option--LCLED
Common Parts
