Introduction
The L.E.D. Warrior™ represents an effective warning signal device. The product has been designed to be easily
installed and operated. A list of standard features is shown below for each model. The Warrior utilizes st ate-of
-the-art L.E.D.s TORUS™ Optics to produce a true emergency level signal available in Red, Amber, Blue and
White. The Gladiator™ LCLED™ model uses more economical LEDs and reflector optics. These lightheads
last longer and use less current than standard halogen or strobe lamps.
Standard Features
Warrior 6-UP 72586
2 Side by side head L.E.D. warning Flashing system
9' power cord with cigarette plug-in provided
10-16 Vdc operation
Current: .5A Red/Amber flashing, .8 A Blue/White Flashing, 1.0A R/A Steady Burn, 1.6A B/W Steady Burn
Reverse polarity protection
21 Flash patterns, controlled with flash pattern change button built into housing.
Warrior 3-Up 72586
1 Head L.E.D. flashing system
9' power cord with cigarette plug-in provided
10-16 Vdc operation.
Current: .25A Red or Amber Flashing, .4A Blue or White Flashing, .5A R/ A Steady Burn, .8A B/ W Steady Burn.
Reverse polarity protection
10 flash patterns, externally controlled with flash pattern change button.
Gladiator LCLED
1 Head economical L.E.D. flashing system
9' Power cord with cigarette plug-in provided
10-16 Vdc operation
Current: .2A or less all modes.
Reverse polarity protection
4 Flash patterns, externally controlled with flash pattern change button.
All Models: Temperature Range: -40 C to 84 C (-40 F to 185 F)
The use of this or any warning device does not insure that all drivers can or will observe or
react to an emergency warning signal. Never take the right-of-way for granted. It is your
responsibility to be sure you can proceed safely before entering an intersection, driving
against traffic, responding at a high rate of speed, or walking on or around traffic lanes.
The effectiveness of this warning device is highly dependent upon correct mounting and
wiring. Read and follow the manufacturer’s instructions before installing or using this device.
The vehicle operator should insure daily that all features of the device operate correctly. In
use, the vehicle operator should insure the projection of the warning signal is not blocked by
vehicle components (i.e.: open trunks or compartment doors), people, vehicles, or other
obstructions. This equipment is intended for use by authorized personnel only. It is the
user’s responsibility to understand and obey all laws regarding emergency warning devices.
The user should check all applicable city, state and federal laws and regulations.
Code 3 , Inc., assumes no liability for any loss resulting from the use of this warning device.
Proper installation is vital to the performance of this warning device and the safe operation of
the emergency vehicle. It is important to recognize that the operator of the emergency
vehicle is under psychological and physiological stress caused by the emergency situation.
The warning device should be installed in such a manner as to: A) Not reduce the output
performance of the system, B) Place the controls within convenient reach of the operator so
that he can operate the system without losing eye contact with the roadway.
Emergency warning devices often require high electrical voltages and/or currents. Properly
protect and use caution around live electrical connections. Grounding or shorting of electri-
cal connections can cause high current arcing, which can cause personal injury and/or
severe vehicle damage, including fire.
PROPER INSTALLATION COMBINED WITH OPERATOR TRAINING IN THE PROPER USE
OF EMERGENCY WARNING DEVICES IS ESSENTIAL TO INSURE THE SAFETY OF
EMERGENCY PERSONNEL AND THE PUBLIC.
!
WARNING!
