Installation & Mounting-NGPI Twist Lock Version
Step-1. Locate the NGPI light bulb plug (see Figure 1).
Step-2. Remove the NGPI light bulb plug by rotating it counter clockwise until the bulb plug relsases (see
Figure 2).
Step-3. Take note of the positions of the retention cam clearance notches and Insert the Twist Lock Hide A
Blast unit so that the retention cams fit through the holes in the NGPIs headlight assembly (see Figure 3 and
then 4).
Step-4. Rotate the Twist Lock Hide A Blast Unit clockwise as far as it goes to lock it into place in the NGPI
headlight housing (see Figure 5 page 9)
FIGURE 1
FIGURE 2
FIGURE 4 FIGURE 3
