Arrowstik® modules – Code 3 Triumph User Manual
Page 8

ArrowStik® Modules
Selecting the ArrowStik Pattern
The Central Controller is designed to offer user selectable traffic directing and traffic warning flash patterns. Each of the ArrowStik functions (LEFT,
CENTER-OUT, RIGHT or FLASH) can be programmed individually for unique patterns and flash rates. This allows the greatest flexibility when
controlling the various light bar configurations available. The light bar can be ordered with a 5, 6, 7 or 8 lighthead configuration. The light bar
will come from the factory with the Building Fast pattern as the default for LEFT, CENTER-OUT and RIGHT. The default pattern for FLASH is the
Standard Flash. If it is desired to change the pattern for any of the functions, follow the programming procedure below.
STEP 1:
Power-up the light bar. Select the ArrowStik function that you wish to program (LEFT, CENTER-OUT, RIGHT or FLASH).
Make sure +12v is only applied to the function you are trying to program - otherwise program function will not
operate.
STEP 2:
Continue applying power to the wire(s) from Step 1. Refer to Table 5 for the available flash patterns. To increment to the next pattern, momentarily
hold the BLK/RED wire to +power for less than two seconds and then release. The four corner light heads will turn on steady to indicate that the
pattern has been incremented. To decrement to the previous pattern, momentarily hold the BLK/RED wire to +power for two to four seconds and
then release. The four corner light heads will turn on steady and then turn off to indicate that the pattern has been decremented. After the pattern
selection wire has been released, the new pattern will begin to flash and is automatically stored each time.
Notice that for the LEFT, CENTER-OUT and RIGHT functions there are four pattern choices (Building, Building with 3 Flash for the end lightheads,
Traveling Ball with 3 Flash for the end lightheads, and Build/Collapse) and three speeds (Fast, Medium and Slow). There are a total of twelve
possible selections for each function and then you return to the top selection.
For the FLASH function there are nine traffic warning patterns available. Flash patterns marked with an asterisk “*” can be selected in Fast, Medium
or Slow flash rate.
NOTE: To restore the Factory Default Arrowstik Flash Patterns, hold the BLK/RED to +power for more than four
seconds. The four corner light heads will turn on steady, turn off and then turn on steady again to indicate that
the Factory Default Arrowstik Flash Patterns have been restored.
STEP 3:
Repeat steps 1 through 2 for the other ArrowStik functions as desired.
TRAFFIC DIRECTINg / TRAFFIC wARNINg FLASH PATTERNS
Mode
LEFT
CENTER-OUT
RIgHT
FLASH
1
Building
Building
Building
Standard Flash*
2
Building, 3 Flash
Building, 3 Flash
Building, 3 Flash
Quad Flash Standard
3
Traveling Ball, 3 Flash
Traveling Ball, 3 Flash
Traveling Ball, 3 Flash
Simultaneous Flash*
4
Build/Collapse
Build/Collapse
Build/Collapse
Quad Flash Simultaneous
5
Even/Odd Flash*
6
Quad Flash Even/Odd
7
Left/Right Flash*
8
Quad Flash Left/Right
9
Traveling Ball Flash*
All Patterns have a fast,
medium, or slow speed.
All Patterns have a fast,
medium, or slow speed.
All Patterns have a fast,
medium, or slow speed.
Patterns with the * have a fast,
medium, or slow speed.
Table 5
