Code 3 LP 6000 - Manual (Page 10)

10
Parts List
Ref No. Description Part No. Qty.
12 #8 x .270" Hex Head Sheet Metal Screw T01215 --
13 Rotating Motor Ass--(Does not include Reflector Assy)
Rotator Motor Assy 55W H-1 Std Speed S95978M --
Rotator Motor Assy 55W H-1 Fast Speed S95979M --
Rotator Motor Assy 50W Bayonet Std Speed S95980M --
Rotator Motor Assy 50W Bayonet Fast Speed S95981M --
Rotator Motor Assy 24V S95982M --
14 #8 x .270" Hex Head Sheet Metal Screw T01215 --
15 #10 Machine Screw Washer T00154 --
16 L.P. Half Mirror Module S40002M --
17 L.P. Speaker cover/lens Hold down Bracket T00918 2
18 #8 x .270" Hex Head Sheet Metal Screw T01215 --
19 L.P. Motor Assembly See #13 --
20 L.P. Stationary Filter -Blue T01280 --
-Amber T01281 --
-Red T01279 --
-Green T01299 --
21 L.P. Frame -(38") S85145M 1
-Regular (47") S85146M --
-Long (55") S85147M --
22 Speaker Bell S91474M --
23 Speaker Mounting Screws T00154 --
