Common Backing Plate is used for all surface-mount
side rail lighting application options.
t57094 Backing plate
NOtE:
All clamping parts of assembly to chrome rails require
(1) anti-vibration pad t56311 to be installed at each
contact point.
1. optix 3 up Dual stack light heads
hD3223 2. optix 6 up Dual stack light heads
hD3226
3. tandem leD-X Dual stack light heads
hD3238 4. Dual stack leD-X light heads
hD3228
Surface mounted Side brackets are installed with bolt threads facing in on assy. toward bike.
“surface-mount” side lighting options
NOtE:
t56311 ANtI-VIBRAtION PADS ARE
REQUIRED At ALL BRACKEt MOUNt-
ING POINtS IN CONtACt WItH CHROME
RAILS OF BIKE. (8) ARE INCLUDED IN tHE
ASSEMBLY SHOWN.
OPtIX 6-UP DUAL StACK ASSEMBLY
SHOWN
hD3226 shoWn
chRome bRackets aRe unIQue to lIght heaD
selectIon maDe.
backIng Plates anD haRDWaRe aRe common
to all assemblIes shoWn beloW.
t57094
backIng
Plate
t03400 heX heaD ss bolt
t03734 nYloc nut
hD3226 shoWn InstalleD
