“on the Rail” Rear lighting options
Common Backing Plate and Bracket are used on all
Rear lighting application options.
t57098 Backing plate
t57097 Bracket (Chrome)
NOtE:
All clamping parts of assembly to chrome rails require
(1) anti-vibration pad t56311 to be installed at each
contact point.
1. optix 3 up light head
hD2123 2. optix 6up light head
hD2126
3.Dual stack Xt3 light head
hD2103
Rear bracket installations are generally easier made with side saddle bags removed from bike.
4. Xt3 (3) way license plate
bracket
hDlPbkt
t57097 chRome
bRacket
t15104 ss bolt
t03734 nYloc
nut
t57098 backIng Plate
NOtE:
t56311 ANtI-VIBRAtION PADS ARE
REQUIRED At ALL BRACKEt MOUNt-
ING POINtS IN CONtACt WItH CHROME
RAILS OF BIKE. (8) ARE INCLUDED IN tHE
ASSEMBLY SHOWN.
Rear license Plate lighting
oPtIX 6-uP lIght heaD
assemblY shoWn
hD2126 shoWn
chRome bRackets, backIng Plates & haRDWaRe aRe
common PaRts to all assemblIes shoWn beloW.
hD2126 shoWn InstalleD
