Code 3 DuoBeam II - Manual (Page 7)

7
FP# Single Color Multi-Color FP# Multi-Color
1 Cycle Flash Sim. 70 fpm Cycle Flash Sim. 70 fpm 25 Variable Single Alt. (primary)
2 Cycle Flash Alt. 70 fpm Cycle Flash Alt. 70 fpm 26 Cycle Flash Sim. 150 fpm (primary)
3 NFPA Quad Sim. 80 fpm NFPA Quad Sim. 80 fpm 27 Cycle Flash Alt. 150 fpm (primary)
4 NFPA Quad Alt. 80 fpm NFPA Quad Alt. 80 fpm 28 Single Sim. 250 fpm (primary)
5 Triple Simultaneous 70 fpm Triple Simultaneous 70 fpm 29 Single Alternating 250 fpm (primary)
6 Triple Alternating 70 fpm Triple Alternating 70 fpm 30 Rotate (primary)
7 Double Simultaneous 70 fpm Double Simultaneous 70 fpm 31 Cruise (primary)
8 Double Alternating 70 fpm Double Alternating 70 fpm 32 Cycle Flash Sim. 70 fpm (secondary)
9 Variable Single Sim. Variable Single Sim. 33 Cycle Flash Alt. 70 fpm (secondary)
10 Variable Single Alt Variable Single Alt 34 NFPA Quad Sim. 80 fpm (secondary)
11 Cycle Flash Sim. 150 fpm Cycle Flash Sim. 150 fpm 35 NFPA Quad Alt. 80 fpm (secondary)
12 Cycle Flash Alt. 150 fpm Cycle Flash Alt. 150 fpm 36 Triple Sim. 70 fpm (secondary)
13 Single Sim. 250 fpm Single Sim. 250 fpm 37 Triple Alt. 70 fpm (secondary)
14 Single Alternating 250 fpm Single Alternating 250 fpm 38 Double Sim. 70 fpm (secondary)
15 Rotate Rotate 39 Double Alt. 70 fpm (secondary)
16 Cruise Cycle Flash Sim. 70 fpm (primary) 40 Variable Single Sim. (secondary)
17 - Cycle Flash Alt. 70 fpm (primary) 41 Variable Single Alt (secondary)
18 - NFPA Quad Sim. 80 fpm (primary) 42 Cycle Flash Sim. 150 fpm (secondary)
19 - NFPA Quad Alt. 80 fpm (primary) 43 Cycle Flash Alt. 150 fpm (secondary)
20 - Triple Simultaneous 70 fpm (primary) 44 Single Sim. 250 fpm (secondary)
21 - Triple Alternating 70 fpm (primary) 45 Single Alternating 250 fpm (secondary)
22 - Double Simultaneous 70 fpm (primary) 46 Rotate (secondary)
23 - Double Alternating 70 fpm (primary) 47 Cruise (secondary)
24 - Variable Single Sim. (primary)
Progressive vs. Independent Switching
Depending on how the blue, orange, and yellow activation wires are connected, different levels of control are
possible. For example, activating the blue wire allows a flash pattern to be set. Activating the blue + orange
wires allows a different pattern to be set. Activating only the orange wire allows yet another to be set. Seven
combinations are possible.
Flash Pattern Selection (Very important - read carefully)
Energize (+12VDC) to the red wire and ground the black wire. Energize the activation wires desired to begin
flashing the lightheads. Observe the flash pattern (Default). Change the flash pattern as follows:
If touched for 0-2 seconds, the lighthead will steady burn dimly and the next pattern in line will begin when
the green wire is deactivated.
If touched for 2-4 seconds, the lightheads will shut off and the previous pattern will begin when the green
wire is deactivated.
If touched for more than 4 seconds, the lightheads will shut off and then turn on again. All patterns will
be reset to factory default.
The pattern that is selected will be stored even when power is removed.
There are 16 patterns for single color models and 47 for multi-color models. Alternating refers to a pair of
lights flashing together while simultaneous refers to all heads (of the same color) flashing together.
Diagnostic Test
There is also a diagnostic test that can be run using the Green pattern change wire. Apply +12V to the Green
wire (only). The lights will turn on one at a time and then turn off. Note that it can only be activated by apply-
ing power to the Green wire at start up. If the unit has been energized with any other wire, power needs to be
removed entirely from the light bar before applying power to the Green wire to enter into this mode again.
Dimming Operation
The DuoBeam can be operated in a low power "Dimming" mode. Dimming is controlled by connecting the
White wire to +12VDC. When Dimming is engaged, the lighheads will operate in reduced power mode.
