3

FIGURE 3

RED WIRE - HIGH VOLTAGE

BLACK WIRE - GROUND (EARTH)

WHITE WIRE - TRIGGER

Installation

This is a full size template.
Do not use a facsimile or
copied reproduction. Do
not use this template if the
largest dimension in each
direction is not within +/-.010.

WARN-
ING!

!

FIGURE 2

FIGURE 1

INTERIOR WALL OF VEHICLE OR
NEAREST OBSTACLE DIRECTLY BEHIND
LIGHT HEAD

2.000 MINIMUM

EXTERIOR WALL OF VEHICLE

SHIELD WIRE
(CUT FLUSH)
