Page 3
INTRODUCTION
This manual covers the calibration, repair, maintenance and a troubleshooting guide to
identify and remedy problems that could occur with CDI Torque Screwdrivers. Each
wrench model has an Exploded Illustration that lists the component parts and shows
assembly particulars. The exploded illustration must be used as a guide for assembling
the screwdrivers.
CDI has a Service Centers that performs repairs and calibration on all of our products at
the factory, plus a list of factory authorized repair/calibration centers throughout the
world. Contact CDI Sales or Service Center at (626) 965-0668 or
[email protected]
for
technical assistance on the repair or calibration of CDI products.
CLEANING
Wipe all exterior parts with a dry, clean and lint free cloth. DO NOT USE any abrasive
or corrosive materials to clean any components of CDI Torque Wrenches.
LUBRICATION
Super Lube MULTI-Purpose Synthetic Lubrication with Teflon, CDI Part #10-
1000. NO SUBSTITUTES ALLOWED.
REPAIR TOOLS REQUIRED
CDI Torque Screwdrivers
* Torque Tester (range determined by the torque wrench to be tested)
1 1/8” Hex “T” shape
1 9/16” Open End Wrench
1 ¾” Open End Wrench
1 QC1I200Torque Wrench
1 1/16” Hex
1 3/8” Sq. Dr. ratchet head “J” shank
*We recommend that CDI torque testers be used to test the calibration accuracy of
CDI manufactured torque products.
CDI manufactures a complete line of torque testing equipment from moderately
priced testers to complete state of the art test systems used in metrology calibration
laboratories all over the world. Contact CDI Sales or Service Center at (626) 965-
0668 or [email protected] .
