P4.x
0,1,2,3,4,
5,6,7
2
0=no RS232 function; 1=output display data when
PRINT pressed; 2=output gross, tare and net
weight when PRINT pressed; 3=continuously
output display data; 4= continuously output gross,
tare and net weight; 5=output display data one
time when scale is stable; 6=output gross, tare and
net weight one time when scale become stable;
7=Bio-RS232 compatible to NCI-SP1
P5.x 0, 1, 2, 3, 4 3
Baud rate for RS232: 0=1200bps, 1=2400bps,
2=4800bps, 3=9600bps, 4=19200bps
P6.x 0, 1, 2 0 RS232 format: 0=8N0, 1=7O1, 2=7E1
P7.xy 00-31 9
Resolution select: 500,600,750,800,1000,1200,
1500,2000,2400,
2500 , 3000, 3500, 4000, 5000,
6000, 7000, 7500, 8000, 10000, 12000, 15000,
20000, 25000, 30000, 35000, 40000, 50000,
60000,70000,75000,80000,100000
P8.x 0,1, 2 1 Division select: 0=1, 1=2, 2=5
P9.x
0,1,2,3,4,
5
1
Decimal point in calibration: 0=Ч1, 1=Ч0.1 , 2=Ч
0.01; 3=Ч0.001; 4=Ч0.0001; 5=Ч10
P10.x 0, 1 1 Calibration unit: 0=kg, 1=lb
P11.x
0, 1, 2, 3,
4, 5, 6
6
Weighing units enable: 0=only kg; 1=only lb;
2=only lb:oz; 3=kg or lb; 4=kg or lb:oz; 5=lb or
lb:oz; 6=kg, lb, or lb:oz
P12.x
0, 1, 2, 3,
4, 5, 6, 7,
3
Power-on zero-point range:
0=calibration zero -point +1%FS;
1=calibration zero -point +2%FS;
2=calibration zero-point +5%FS;
3=calibration zero-point +10%FS;
4=calibration zero-point +20%FS;
5=calibration zero-point +50%FS;
6=calibration zero-point +100%FS;
7=No limitation
28
P13.x
0,1,2,3,4,
5,6,7
2
Zero range for ZERO button:
0= Power-on zero-point +1%FS;
1= Power-on zero-point +2FS;
2= Power-on zero-point +5%FS;
3= Power-on zero-point +10%FS;
4= Power-on zero-point +20%FS;
5= Power-on zero-point +50%FS;
6= Power-on zero-point +100%FS;
7= No limitation
P14.x 0, 1, 2 2
Weight signal within power-on zero point range,
Choose which data as current power-on zero point;
0= current weight ; 1= calibration zero-point;
2=switch-off zero-point
P15.x 0, 1, 2 1
Weight signal not within power-on zero point
range, Choose which data as current power-on zero
point; 0= current weight ; 1= calibration
zero-point; 2=switch-off zero-point;
3=continuously display “0ˉˉˉˉ”
P16.x
0, 1, 2, 3,
4, 5, 6,7,8
8
Zero tracking range: 0=0d, no tracking; 1=+0.25d;
2= +0.5d; 3=+1d; 4=+1.5d; 5=+2d; 6=+3d; 7= +4d;
8=+5d
P17.x 0, 1, 2, 3 2
Data filter intensity: 0=very weak, 1=weak,
2=middle, 3=strong
P18.x 0, 1….9 1
Check weight stability range: 0=+0.5d; 1=±1d ;
2=+1.5d; 3=+2d; 4=+3d; 5=+4d ; 6=+5d ; 7=+6d ;
8=+7d; 9=+8d
P19.x 0, 1….9 1
Overload limit range: 0=FS+0d; 1=FS+9d;
2=101%FS; 3=102%FS; 4=105%FS; 5=110%FS;
6=120%FS; 7=150%FS; 8=200%FS; 9=No
limitation
