5.1 Entering configuration mode

5 Configuration Mode

S122

User /

Service Instructions

Configuration Mode

5.1

Entering configuration mode

In order to enter configuration mode you must first set the
configuration switch to the unlocked position. The switch is
located under the tamper proof seal above the serial comm

unication

socket on the right-hand side of the head.

Set the configuration switch to
the unlocked position.

Locked position

Unlocked position
